Specification of cylinder body | 10L |
Applicable Sing-Use bag volume | 10L |
control system | Siemens PLC, 15-inch color touch screen, Ethernet interface, USB interface |
temperature control | Heating blanket temperature control, PID automatic control, Pt 100 sensor, control accuracy: ± 0.5℃, temperature control range: 8-45℃ above the coolant temperature, up to 60℃ |
Maximum mixing speed | 360RPM |
ventilate※ | Four heat mass flowmeters (Air, O2, N2, CO2), one heat mass flowmeter is optional with three air mixing; surface ventilation module is optional |
Exhaust control | exhaust gas filter heater, 0.2 μ m exhaust gas filter |
gas concentration※ | O2 concentration (0-50%), CO2 concentration (0-20%), optional air intake or exhaust |
Gas pressure control | The bag pressure can be detected and controlled |
PH&DOelectrode |
Option 1 | Disposable optical PH electrode, detection and control range: 6-8, automatic PID control, cascaded peristaltic pump, CO2 concentration, etc |
Option 2 | Reatability with traditional PH electrode sheath, detection and control range: 4-10, automatic PID control, cascade peristaltic pump, CO2 concentration, etc |
Option 1 | Option 1: disposable optical DO electrode, detection range: 0-200%, automatic PID control, cascade stirring speed, ventilation volume, etc |
Option 2 | Optional 2: repeatability Use traditional DO electrode equipped with sterilization electrode sheath, detection and control range: 0-200%, automatic PID control, cascade mixing speed, ventilation, etc |
Squeeze pump group※ | Four fixed-speed peristaltic pump sets can be customized feeding, acid, alkali, etc., 25 RPM / 100 RPM can be selected. |
Weighing module※ | Optional, can be cascade with parameters such as peristaltic pump |
signal interface※ | External peristaltic pump optional; external weighing system optional |
public service | Air, O2, N2, CO2, pressure requirement: 30-35 PSIG |
source | AC220V，50/60HZ，20A |
